RH-25L(A) Horizontal (Linear Guide) Slant Bed CNC Lathe

X and Z guide rails are both linear guide rails; excluding: chuck, turret, center frame, motor, electrical components, electrical box, and inner and outer protective metal parts of the main machine, assembled, inspected, and painted according to relevant international and domestic standards.

Key words:

Yunnan Runhang

precision machinery

CNC lathe

hard rail lathe

Classification:

Product Consulting:

Product Description

Both X and Z guide rails are linear guide rails; excluding: chuck, turret, center frame, motor, electrical components, electrical box, and internal and external protective metal parts of the main machine, assembled, inspected, and painted according to international and domestic relevant standards.

Standard configuration:

1. High-quality resin sand casting;

2. Screw rod (PMI/HIWIN);

3. Roller linear guide (PMI/HIWIN);

4. Spindle assembly: the spindle is an NN structure assembled spindle, and the spindle bearings use imported "SKF/NSK" bearings;

5. Main motor pulley and belt;

6. Screw rod bearings (NSK/FAG);

7. One coupling for X/Z direction;

8. Packaging: wooden base + rust prevention + moisture-proof.

Special configuration: (This configuration can be customized according to customer requirements, with additional pricing):

1. Hydraulic chuck and high-speed rotary cylinder. (Germany ROHM/Korea RYON/Taiwan Yichuan/Domestic Keput) installed and dynamically balanced;

2. Turret; Zhengtong turret, Sanhe turret. (Including installation);

3. Hydraulic center frame and bracket assembly;

4. Sheet metal (including internal and external protection)

5. Hydraulic station; (Taiwan Weisheng, Domestic Jianhua) installed, oil circuit distribution and installation;

5. Hydraulic controllable tailstock;

6. Built-in rotating tailstock sleeve.
